Push Wheel

PF21 PF31 PF43 PF44
PF46 PF49 PF52 PF52-PP
PF54 PF54-PP PR52 TF31

TF41 TF51 TR51 配件Colors

Operating voltage : 50V AC, 28V DC
 Switching current : 100mA max
 Carrying current : 1A max
 Contact resistance : 200mΩ max
 Operating temperature : -20°C to 65°C
 Storage temperature : -25°C to 85°C
lnsulation resistance :
    Between live & dead parts 1000MΩ min.
    Between live & parts 10MΩ min
 Dielectric strength :
    Between live & dead parts 1000V AC 1 minute
    Between live & parts 800V AC 1 minute
 Life :
    Mechanical 200,000 operations min.
    Electrical 100,000 operations min.
