- DESCRIPTION
- MECHANICAL LIFE: 40.000 make-and-break cycles
- CONTACT RATING: 0.4 VA max.@ 20 V AC or DC max
- CONTACT RESISTANCE: Below 100 m Ohm typ. initial @ 2-4 V DC, 100mA.
- INSULATION RESISTANCE: 1,000M.Ohm min
- DIELECTRIC STRENGTH: 500 V RMS@sea level.
- OPERATING TEMPERATURE: -30 degreeC to 85 degreeC
- MATERIAL
- HOUSING AND BASE: Glass filled nylon 66 or 4/6 flame retardant,heat stabilized ( UL 94V-0 )
- ACTUATOR: Glass filled nylon6/6,flame retardant,heat stabilized(UL94V-0),with standard internal o-ring seal
- SWITCH SUPPORT: Copper alloy,with gold plated over nickel plated
