Mechanical life：300,000 cycles min ；
(each upright and opposite rotate 150,000/cycles)
Electrical life ： 300,000 cycles min ；
(each upright and opposite rotate 150,000/cycles)
Contact Rating：1 mA @10 VDC ；
Insulation Resistance：＞ 50M Ω DC50V ；
Withstand Voltage：AC50V 1 minute ；
Contact Resistance：＜ 10 Ω；
Ambient Humidity：＜ 85%RH ；
Operating Temper： -10 ℃ to 65 ℃；
Operating Force：20gf ； 25gf.
Soldering process：Hand Soldering ： Use a soldering iron of 30 watts ， controlled at 380 ℃ approximately 3 seconds while applying solder 。
Wave soldering：When applying wave soldering, the peak temperature of the wave Oven should be set to 260 ℃ max. Condition for soldering (Wave & Non-washable Type) Temperature Profile：（ Figure 1 ）
Reflow soldering：When applying reflow soldering, the peak temperature of the reflow Oven should be set to 250 ℃ max. Condition for soldering (Reflow & Non-washable Type) Temperature Profile：（ Figure 2 ）
