SP3T, DP4T, PCB mounting

4A 125VAC, 2A 250VAC (UL, CSA)

Contact resistance : 50m ohm  (MAX).

Insulation resistance : 100M ohm  (MIN), DC 500V

Dielectric strength : 1000VAC FOR 1 MINUTE

Enclosure : PBT / Nylon, UL rated 94V-2 min

Base : PBT / Nylon, UL rated 94V-2 min

Actuator : PBT/Nylon, UL rated 94V-2 min

Contact arm : Copper

String: Steel wire

Terminals : Copper alloy
