SPST, SPDT, panel mounting or snap-in available

12A 125/250VAC (UL), 4A 300VAC(UL)

10A 125/250VAC (UL), 4A 300VAC(CSA)

10(1)A 250V~μT85 (VDE,SEMKO,DEMKO,NEMKO,FIMKO,SEV)

Contact resistance : 50m ohm  (MAX).

Insulation resistance : 100M ohm  (MIN), DC 500V

Dielectric strength : 1000VAC FOR 1 MINUTE

Enclosure : PBT / Nylon, UL rated 94V-2 min

Base : PBT / Phenollic, UL rated 94V-2 min

Actuator : PBT, UL rated 94V-2 min

Movable Contact : Silver plated Copper

Terminals : Silver plated Copper

Contact Spring : Spring steel
