HB SERIES

SPST, SPDT ROCKER SWITCHES UP TO 20A 125VAC, IP42 RATING, T125
classical outlook, crystal lighting, 6A "L", splash protected



  • Double shot rocker available, visi color

  • Classical outlook, full or soft lighting

  • 20A 125VAC / 16A 250VAC (UL,CSA)

  • 3/4 HP 125VAC, 3/4 HP 250VAC (CSA)

  • 6A 125VL, 3/4HP 250VAC(UL)

  • 16(4) A 250VAC~T125 (VDE,SEMKO,DEMKO,NEMKO, FIMKO,SEV)

  • 16A 250VAC (CQC)

  • Initial contact resistance : 20m ohm max.

  • Insulation resistance : 100M ohm  min, at 500VDC

  • Dielectric strength : 1,000VAC for 1 minute

  • Electrical life : 10,000 cycles

  • Temperature range : -20 to +125 degrees in Celsius

  • Switch for Class II appliances

  • Base : Nylon 66, UL rated 94V-2 min

  • Actuator : Nylon 66 or PC, UL rated 94V-2 min

  • Spring : Piano wire

  • Contacts : Silver alloy

  • Terminals : Silver plated copper

  • Lamp : Neon

　

HB110-C2L-BRN-A

HB110-C2N-BBG-A

HB180-C2N-BBN-M

HB130-C8N-BRN-W
