4B Miniature Rocker Switches

Product : Rocker Switch >> 4B Series

DESCRIPTION CONTACT RATING: Dependent upon contact material MECHANICAL LIFE: 50,000 make-and-break cycles at full load CONTACT RESISTANCE: 20m.Ohm max. initial @ 2-4VDC 100mA for both silver and gold plated contacts INSULATION RESISTANCE: 1,000M.Ohm min. DIELETRIC STRENGTH: 1,000 V RMS@sea level OPERATING TEMPERATURE: -30 degreeC to 85 degreeC MATERIAL CASE & BUSHING - Glass filled nylon 4/6,flame retardant, heat stabilized ( UL 94V-0 ) ACTUATOR - Nylon,black std.lnternal O-ring seal standard witch all actuators SWITCH SUPPORT - Brass or steel , tin plated TERMINALS/CONTACT- Copper alloy,with silver or glod plated
