Specification：
| (Q) Fixed terminal: | Silver plated copper alloy |
| Moving contact: | Silver plated copper alloy |
| Rating: | 5 Amps with resistive load @ 120VAC or 28VDC 2 Amps with resistive load @ 250 VAC |
| (R) Fixed Terminal: | Copper alloy with gold plate over nickel plate |
| Moving contact: | Copper alloy with gold plate over nickel plate |
| Rating: | 0.4 Volt-Amps (VA) max. @ 20V max (AC or DC) |
| Electrical Life: | 50,000 make-and-break cycles at full load. |
| Contact Resistance: | 10 milli ohm max. initial @ 2- 4 VDC, 100 mA for both silver and gold plated contacts. |
| Insulation Resistance: | 1,000 M ohm min. |
| Dielectric Strength: | 1000 V RMS @sea level. |
| Operating Temperature: | -30oC to 85oC |
| Materials： Case: Diallyl phthalate (DAP)(UL94V-0) Rocker: Nylon Bushing: Brass, nickel plated Housing: Stainless Steel Switch Support: Brass, tin plated Terminal/Contact: Brass, with Silver or gold plated. |
|
