Specification：
| (Q) Fixed terminal: | Silver plated copper alloy |
| Moving contact: | Silver plated copper alloy |
| Rating: | 5 Amps @ 120VAC or 28VDC 2 Amps @ 250 VAC |
| (R) Fixed Terminal: | Copper alloy with gold plate over nickel plate |
| Moving contact: | Copper alloy with gold plate over nickel plate |
| Rating: | 0.4 Volt-Amps (VA) max. @ 20V max (AC or DC) |
| Electrical Life: | 30,000 make-and-break cycles at full load. |
| Contact Resistance: | 10 milli ohm max. initial @ 2- 4 VDC, 100 mA for both silver and gold plated contacts. |
| Insulation Resistance: | 1,000 M ohm min. |
| Dielectric Strength: | 1000 V RMS @sea level. |
| Operating Temperature: | -30oC to 85oC |
| Materials： Case & Bushing: Glass filled nynon6/6, flame retardant, heat stabilized (UL94V-0) Actuator: Nylon, black std. Internal o-ring seal standard with all actuators. Frame: Spring steel, black std. Switch Support: Brass or steel, tin plated Actuator Pivot & Mounting Bracket: Nylon Actuator Pivot Retainer: Stainless steel. Contact/Terminals: Silver or Gold plated copper alloy. |
|
