LOW PROFILE MAIN
POWER SWITCHES
PS-5 SERIES
|
DPST,SPST, cleat or
snap in 13X19mm, illuminated
|
|
|
- 16A 125/250VAC (UL, CSA)
- 16(4)A 250VAC~ T125/55 (VDE,SEMKO,DEMKO,NEMKO,FIMKO,SEV)
- 16(8)A 250V~T125/55 (VDE, ENEC)
- Initial contact resistance : 20m max.
- Insulation resistance : 100M min, at
500VDC
- Dielectric strength : 1,000 VAC for 1
minute
- Temperature range : -20to +125degrees in
celsius
|
-
Switch for
class II appliances
-
Base :
Nylon 66/PBT, UL rated 94V-2 min
-
Actuator :
Nylon 66/PC, UL rated 94V-2 min
-
Spring :
Piano wire
-
Contacts :
Silver alloy
-
Terminal : Silver plated copper
|
|
|
|
|
|
PS5-212-L0 |
|
 |
|
|
|
PS5-210-PL-BO-S |
|
 |
|
|
|
PS5-210-PL-BR-SW |
|
|
|
 |
